Description

Siemens DEKA 46lb/hour with EV6 / USCAR Connector - Direct fit for SRT , LS2 & LS7

Genuine Siemens DEKA High Impedance Injectors

These injectors flow 46.5 lbs/hr at 43.5 PSI ( 3 BAR ) and much more at higher PSI! In addition, these units are high-impedance. Despite the high flow rate, they are linear and controllable at low pulse widths and have been used in ULEV applications! This allows you to use a larger injector than normally possible without hurting idle and low speed driveability. Adding to the flexibility of application, these units are high-impedance; making them compatible with most ECUs, while delivering the most flow available in a High-Impedance injector. These injectors represent the most current Siemens DEKA engineering and are used on many high power turbo and supercharged oem applications.

These injectors are able to function at high fuel pressures and don’t exhibit the high fuel pressure handling problems found with many other high flow high-impedance injectors. This makes these injectors very well suited to turbocharged and supercharged applications that see high fuel system pressures and in fact, that is exactly what they were designed for!

Engine performance and running quality are enhanced through the optimized spray pattern. Unlike competitors “pencil stream” high flow injectors; these High Flow injectors utilize a multi-orifice tip for improved mixture preparation and atomization. This results in lower BSFC and better idle quality than many injectors with less flow.

Features:

• Genuine, reliable Siemens Injectors
• Excellent response characteristics
• Robust Design
• High Impedance
• Low Impedance performance characteristics with High Impedance Compatibility

• Coil Resistance: 12 Ohms (This high-impedance injector will work with all factory ECM/PCM injector drivers)
• Gain: 0.75
• Spray Pattern: Cone
• Electrical Connector: USCAR (New-style V=EV6 / Oval / LS2)
• Fitted with Viton upper and lower o-rings.
• Static Flow Rate @ 43.5PSI (300kPa): 46.5 lb/hr = 5.86g/s = 478cc/min (+/-3%)
• Static Flow Rate @ 58.0PSI (400kPa): 53.7 lb/hr = 6.77g/s = 552cc/min (+/-3%)
• Dynamic Flow Rate 2.5ms PW @ 100Hz (400kPa): 11.42mg/pulse +/-4%

• Dodge / Chrysler SRT
• Direct fit for LS2 and LS7 Applications!
• Made for high pressure, harsh environment turbo & supercharged applications!

• Siemens FI11351 [pre-2008]
• Siemens FI11354 [post-2008]
• SMP FJ601
• GM 19146088
• Chrysler 4891574AB [pre-2008], 04891574AD [post-2008])
• AC Delco 217-2939

Mating Parts

Connector only:

• CONN-12558 - GM Delphi / Packard - Bosch Type EV6 Injector Connector Assembly ( connector and TPA )

• CONN-75570 - GM Delphi / Packard - Bosch Type EV6 Injector Connector Kit

• CONN-75570p - GM Delphi / Packard - Bosch Type EV6 Injector Connector Kit ( Production Kit )

• CONN-85570 - GM Delphi / Packard - Bosch Type EV6 Injector Connector Pigtail

Specifications

• Static Flow Rate @ 43.5PSI (300kPa): 46.5 lb/hr = 5.86g/s = 478cc/min (+/-3%)
• Static Flow Rate @ 58.0PSI (400kPa): 53.7 lb/hr = 6.77g/s = 552cc/min (+/-3%)
• Dynamic Flow Rate 2.5ms PW @ 100Hz (400kPa): 11.42mg/pulse +/-4%

Applications

• Dodge / Chrysler SRT
• Direct fit for LS2 and LS7 Applications!
• Made for high pressure, harsh environment turbo & supercharged applications!

• Siemens FI11351 [pre-2008]
• Siemens FI11354 [post-2008]
• SMP FJ601
• GM 19146088
• Chrysler 4891574AB [pre-2008], 04891574AD [post-2008])
• AC Delco 217-2939
