VSS Harness Adapter	Part # CONN-86287

Pricing
1 +	$14.99
Information
Bmotorsports Part #	CONN-86287
Availability	In Stock
Shipping Weight	0.005 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

VSS Harness Adapter

This adapter easily converts your mid 90's GM, or similar era Vehicle Speed Sensor/ Output shaft sensor signal to use a newer style VSS sensor, which may be present on your new transmission swap into an older chassis with associated wiring. In some cases, your harness package may have the incorrect connector for which this easily adapts. Available in custom length upon inquiry, 18" standard to reach most locations.

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Connector Housing	CONN-50557	GM Delphi / Packard - 2-way GT 150 3.5mm centerline (sensor side) sealed connector for CLT/VSS
Terminals	CONN-56466	GM Delphi / Packard - GT 150 3.5mm Centerline Male Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Seals	CONN-56559	GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
Connector Kit	CONN-75642	GM Delphi / Packard - 2-way un-shrouded GT 150 3.5mm centerline sealed female Kit for CLT/VSS
Connector pigtail	CONN-85642	GM Delphi / Packard - 2-way un-shrouded GT 150 3.5mm centerline sealed female pigtail for CLT/VSS

Applications

Many applications not listed

Specifications

Parameter Value
Terminal Size 1.5mm
Terminal Type Flat
Min. Wire Gauge 18
Max. Wire Gauge 18

This product contains the following items:
	» 2 x 20AWG Automotive TXL Wire Black Part # WIRE-00458S
	» 2 x 20AWG Automotive TXL Wire Yellow Part # WIRE-04458S
	» 2 x GM Delphi / Packard - Weather-Pack ( Weatherpack ) Cable Seal ( 20 - 16 gauge ) ( purple ) Part # CONN-55560
	» 2 x GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated Part # CONN-56468
	» 2 x GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only Part # CONN-56559
	» 2 x 1/8in. Diameter Clean Cut Expandable Braided Sleeving, Black Part # WIRE-57555
	» 2 x GM Delphi / Packard - Male Metripack 280 Terminal, 18-16 gauge Part # CONN-55855
	» 1 x TPA for 2-way GT 150 3.5mm centerline (sensor side) sealed connector assembly Part # CONN-50558
	» 1 x GM Delphi / Packard - 2-way un-shrouded GT 150 3.5mm centerline sealed female for CLT/VSS Part # CONN-51661
	» 1 x GM Delphi / Packard - mate to 2 way Metripack 280 female connector ONLY for 1993-1994 VSS or H8 / H11 Bulb Connector Part # CONN-51665
	» 1 x TPA for Mate to 2 way Metripack 280 female connector for 1993-1994 VSS or H8 / H11 Bulb Connector Part # CONN-100739
