2 Way Plug Connector Pigtail for Japanese applications, Gray	Part # CONN-85816

Pricing
1 +	$9.99
25 +	$9.75
50 +	$9.49
100 +	$7.99
400 +	$7.49
Information
Bmotorsports Part #	CONN-85816
Availability	In Stock
Shipping Weight	0.15 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

2 Way Plug Connector Pigtail for Japanese applications, Gray. A completed pigtail is provided.

This gray connector is often used on sensors such as speed sensors, knock sensors and others on applications like the Mazda Miata.

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Connector Only	CONN-100518	2 Way Plug Assembly for Japanese applications (Connector + Lock), Gray
Terminals	CONN-100452	Sumitomo HX / DL / SL Sealed Series Female terminal 18 - 16 AWG Terminal, loose piece
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Kit	CONN-75816	2 Way Plug Connector Kit for Japanese applications, Gray
Pigtail	CONN-85816	2 Way Plug Connector Pigtail for Japanese applications, Gray
Mating Parts
Connector Only	CONN-100519	2 Way Receptacle Assembly for Japanese applications (Connector + Lock), Gray
Terminals	CONN-100451	Sumitomo HX / DL / SL Sealed Series Male terminal 18 - 16 AWG Terminal, loose piece
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Kit	CONN-75817	2 Way Receptacle Connector Kit for Japanese applications, Gray
Pigtail	CONN-85817	2 Way Receptacle Connector Pigtail for Japanese applications, Gray

Applications

Applications:

Mazda Miata (Most NA, NB Models)
Mazda RX8 Crank Angle Sensor (CAS) / Mazda RX-8
2004 - 2009 FORD F-150 Power Window Motor Connector - REAR RIGHT
2006 - 2008 LINCOLN MARK LT Power Window Motor Connector - REAR RIGHT

Cross References:

WELLS 1025
AIRTEX 1P1657
MOTORCRAFT WPT-767, WPT767
FORD 3U2Z-14S411-ZUA
FORD 3U2Z-14S411-ZUB

Specifications

Parameter Value
Number of Ways 2
Gender Plug/Male
Terminal Size 2.3mm
Terminal Type Flat
Min. Wire Gauge 18
Max. Wire Gauge 16

This product contains the following items:
	» 25 x Labor $0.25/minute Part # LABR-00001
	» 2 x 18AWG Automotive TXL Wire Black Part # WIRE-00459s
	» 2 x Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG) Part # CONN-00119
	» 2 x Sumitomo HX / DL / SL Sealed Series Female terminal 18 - 16 AWG Terminal, loose piece Part # CONN-100452
	» 1 x 2 Way Plug Assembly for Japanese applications (Connector + Lock), Gray Part # CONN-100518
