Honda Injector Connector Mate Kit	Part # CONN-75975

Pricing
1 +	$4.99
5 +	$4.75
10 +	$4.50
20 +	$4.40
50 +	$4.25
100 +	$4.09
Information
Bmotorsports Part #	CONN-75975
Availability	In Stock
Shipping Weight	0.05 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

Honda Style Injector & Coil Connector Mate Kit. Connector Kit. Terminals and seals are included.

This connector receptacle is the same as the connector molded into Honda injectors on millions of applications worldwide. This allows plug n play adapters to be made, breakout harnesses, and all sorts of applications previously unavailable.

This is not an OEM component as no such part is made. In the past, low quality mates were available and we avoided them due to quality problems. This high quality custom part uses genuine OEM terminals and seals and we are happy to finally make this high quality option available to the public!

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-100451	Sumitomo HX / DL / SL Sealed Series Male terminal 18 - 16 AWG Terminal, loose piece
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Housing	CONN-100807	Honda Injector Connector Mate Only
Connector Kit	CONN-75975	Honda Injector Connector Mate Kit
Pigtail	CONN-85975	Honda Injector Connector Mate Pigtail
Mating Parts
Terminals	CONN-100063	HX / DL / SL Sealed Female Terminal for 2 way Sumitomo Honda Injector Connector ( 22 - 20 AWG )
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Housing	CONN-100319	2 way Honda Injector Connector Assembly
Connector Kit	CONN-75783	2 way Honda Injector Connector Kit
Pigtail	CONN-85783	2 way Honda Injector Connector Pigtail

Applications

Honda Injector Side Connector Receptacle
Fits millions of other sensor, injector, coil & solenoid applications

Specifications

Parameter Value
Number of Ways 2
Gender Receptacle/Female
Terminal Size 2.3mm
Terminal Type Flat
Min. Wire Gauge 20
Max. Wire Gauge 16

This product contains the following items:
	» 3 x Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG) Part # CONN-00119
	» 3 x Sumitomo HX / DL / SL Sealed Series Male terminal 18 - 16 AWG Terminal, loose piece Part # CONN-100451
	» 1 x Honda Injector Connector Mate Only Part # CONN-100807
