2 Way HW Plug Conector Pigtail	Part # CONN-85867

Pricing
1 +	$8.49
50 +	$7.99
100 +	$6.99
Information
Bmotorsports Part #	CONN-85867
Availability	In Stock
Shipping Weight	0.005 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

2 Way HW Plug Connector Pigtail, dark gray for industrial proportional solenoids. Connector Pigtail. A completed pigtail is provided.

This 2 Way Sumitomo HW Plug Connector Pigtail is from the OEM connector manufacturer, and the crimp terminations are performed & checked here at our facility in the USA using an factory quality crimp die available as TOOL-00924. Used on Honda B series crankshaft sensors and many different Industrial proportioning solenoids/valve applications, but there may be many other applications not listed as well.

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-11656	Injector Connector Terminal (22 - 16 gauge) [heat resistant copper alloy]
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Housing	CONN-100734	2 Way HW Plug Conector Assembly
Connector Kit	CONN-75867	2 Way HW Plug Conector Kit
Pigtail	CONN-85867	2 Way HW Plug Conector Pigtail

Applications

Honda B series crankshaft sensor
Sensor & Device Connector on other applications

Specifications

Parameter Value
Number of Ways 2
Gender Plug/Male
Terminal Size 2.3mm
Terminal Type Flat
Min. Wire Gauge 20
Max. Wire Gauge 16

This product contains the following items:
	» 10 x Labor $0.25/minute Part # LABR-00001
	» 2 x 18AWG Automotive TXL Wire Black Part # WIRE-00459s
	» 2 x Injector Connector Terminal (22 - 16 gauge) [heat resistant copper alloy] Part # CONN-11656
	» 2 x Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG) Part # CONN-00119
	» 1 x 2 Way HW Plug Front Lock Only Part # CONN-100644
	» 1 x 2 Way HW Plug conector only Part # CONN-100643
