Home » Shop » Sumitomo » 1 Way Sumitomo HX 040 Plug Connector Pigtail, Black

1 Way Sumitomo HX 040 Plug Connector Pigtail, Black	Part # CONN-86113

Pricing
1 +	$7.99
100 +	$6.99
Information
Bmotorsports Part #	CONN-86113
Availability	In Stock
Shipping Weight	0.002 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

1 Way Sumitomo HX 040 Plug Connector Pigtail, Black. Connector pigtail. A completed pigtail is provided.

Fits temperature sender units on many Honda Vehicles

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-100465	Sumitomo HX 040 Female Terminal 0.3 - 0.5mm2 (22 - 20 AWG)
Wire Seals	CONN-100552	Sumitomo HX 040 Seal 0.3 - 0.5mm2 (22 - 20 AWG)
Connector Housing	CONN-100545	1 Way Sumitomo HX 040 Plug Assembly, Black
Connector Kit	CONN-76113	1 Way Sumitomo HX 040 Plug Connector Kit, Black
Connector Pigtail	CONN-86113	1 Way Sumitomo HX 040 Plug Connector Pigtail, Black
Mating Parts

Applications

Fits temperature sender units on many Honda Vehicles

Specifications

Parameter Value
Number of Ways 1
Gender Plug/Male
Terminal Size 1mm
Terminal Type Flat
Min. Wire Gauge 22
Max. Wire Gauge 20

This product contains the following items:
	» 1 x 20AWG Automotive TXL Wire Black Part # WIRE-00458S
	» 5 x Labor $0.25/minute Part # LABR-00001
	» 1 x Sumitomo HX 040 Female Terminal 0.3 - 0.5mm2 (22 - 20 AWG) Part # CONN-100465
	» 1 x Sumitomo HX 040 Seal 0.3 - 0.5mm2 (22 - 20 AWG) Part # CONN-100552
	» 1 x 1 Way Sumitomo HX 040 Plug CONNECTOR ONLY Part # CONN-100576
	» 1 x 1 Way Sumitomo HX 040 Front Lock Part # CONN-100577
