Mate to 4 Way Ford / Mazda MAP Pressure Sensor Connector	Part # CONN-100720

Pricing
1 +	$10.99
25 +	$9.99
50 +	$9.49
100 +	$8.99
250 +	$8.49
1000 +	$7.99
Information
Bmotorsports Part #	CONN-100720
Availability	In Stock
Shipping Weight	0.017 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

Mate to 4 Way Ford / Mazda MAP Pressure Sensor Connector (Connector ONLY!). Connector ONLY. Terminals and seals not included.

Connects to the Bosch sensor sometimes also referred to as the Bosch TMAP Sensor due to the additional of a temperature sensor combined with the MAP sensor. Specific to Ford & Mazda vehicles, not for other platforms. Applications Include:

Mazdaspeed 3
Mazdaspeed 6
Mazda CX-7

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Connector Only	CONN-100720	Mate to 4 Way Ford / Mazda MAP Pressure Sensor Connector
Terminals	CONN-56260	GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Male Terminal ( 20 - 16 gauge )
Seals	CONN-56057	GM Delphi / Packard - Metri-Pack 150 (Metripack) Cable Seal ( 20 - 16 gauge ), white
Connector Kit	CONN-75851	Mate to 4 Way Ford / Mazda MAP Pressure Sensor Connector Kit
Connector Pigtail	CONN-85851	Mate to 4 Way Ford / Mazda MAP Pressure Sensor Connector Pigtail
Mating Parts
Connector Only	CONN-100704	4 Way Ford / Mazda MAP Pressure Sensor Connector
Terminals	CONN-100481	Ford / Yazaki 1.5 Terminal, 18-16AWG
Seals	CONN-56057	GM Delphi / Packard - Metri-Pack 150 (Metripack) Cable Seal ( 20 - 16 gauge ), white
Connector Kit	CONN-75856	4 Way Ford / Mazda MAP Pressure Sensor Connector Kit
Connector Pigtail	CONN-85856	4 Way Ford / Mazda MAP Pressure Sensor Connector Pigtail
Extension
Ford / Mazda TMAP Extension	CONN-85877	4 Way Ford / Mazda MAP Pressure Sensor Extension
Adapters
Ford / Mazda TMAP to Bosch TMAP Adapter	CONN-85824	Ford / Mazda TMAP to Bosch TMAP Adapter

Specifications

Parameter Value
Number of Ways 4
Gender Receptacle/Female
Terminal Size 1.5mm
Terminal Type Flat
Min. Wire Gauge 20
Max. Wire Gauge 16

Used In

Part #	Description
CONN-75851	Mate to 4 Way Ford / Mazda MAP Pressure Sensor Connector Kit
CONN-85851	Mate to 4 Way Ford / Mazda MAP Pressure Sensor Connector Pigtail
CONN-85877	4 Way Ford / Mazda MAP Pressure Sensor Extension
CONN-85824	Ford / Mazda TMAP to Bosch TMAP Adapter
