Toyota Injector Harness to Denso Injector Adapter	Part # CONN-85981

Pricing
1 +	$9.99
50 +	$9.75
100 +	$9.25
Information
Bmotorsports Part #	CONN-85981
Availability	In Stock
Shipping Weight	0.05 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

Toyota Injector Harness to Denso Injector Adapter. Fully assembled adapter included. 2 inch wire length.

Converts from a vehicle harness that used Toyota injector connectors to Denso injectors.

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-11656	Injector Connector Terminal (22 - 16 gauge) [heat resistant copper alloy]
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Housing	CONN-11655	Nippon Denso Type Injector 2 way Connector ( connector only )
Connector Kit	CONN-75572	Nippon Denso Type Injector Connector Kit
Pigtail	CONN-85572	Nippon Denso Type Injector Connector Pigtail
Associated Parts
Terminals	CONN-100069	Sumitomo TS Sealed Series Male Terminal, Brass/Tin ( 20 - 16 gauge )
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Housing	CONN-100806	Toyota Injector Side Connector Receptacle
Connector Kit	CONN-75974	Toyota Style Injector & Coil Connector Mate Kit
Pigtail	CONN-85974	Toyota Style Injector & Coil Connector Mate Pigtail
Mating Parts
Terminals	CONN-100451	Sumitomo HX / DL / SL Sealed Series Male terminal 18 - 16 AWG Terminal, loose piece
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Housing	CONN-100805	Denso Injector Side Connector Receptacle
Connector Kit	CONN-75973	Denso Injector Side Connector Receptacle Kit
Pigtail	CONN-85973	Denso Injector Side Connector Receptacle Pigtail
Mating Parts
Terminals	CONN-11856	Sumitomo TS / SL Female Terminal 0.5 - 1.25 mm2 ( 20 - 16 AWG )
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Housing	CONN-11855	Toyota Style 2 way Injector Connector & Ignition Coil, Gray (connector only) - 90980-11875
Connector Kit	CONN-75757	2-way Toyota Style Injector Connector & Ignition Coil Connector Kit, Gray - 90980-11875
Pigtail	CONN-85757	2-way Toyota Style Injector Connector & Ignition Coil Connector Pigtail, Gray - 90980-11875

Applications

Toyota Fuel Injector Connector to Denso Adapter
Lexus Fuel Injector Connector to Denso Adapter

Specifications

Parameter Value
Number of Ways 2
Terminal Size 2.3mm
Terminal Type Flat

This product contains the following items:
	» 20 x Labor $0.25/minute Part # LABR-00001
	» 1 x 18AWG Automotive TXL Wire Black Part # WIRE-00459s
	» 1 x 18AWG Automotive TXL Wire Red Part # WIRE-02459s
	» 1 x Nippon Denso Type Injector 2 way Connector ( connector only ) Part # CONN-11655
	» 2 x Injector Connector Terminal (22 - 16 gauge) [heat resistant copper alloy] Part # CONN-11656
	» 4 x Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG) Part # CONN-00119
	» 2 x Sumitomo TS Sealed Series Male Terminal, Brass/Tin ( 20 - 16 gauge ) Part # CONN-100069
	» 1 x Toyota Injector Side Connector Receptacle Part # CONN-100806
