Denso Injector Side Connector Receptacle	Part # CONN-100805

Pricing
1 +	$3.99
5 +	$3.75
10 +	$3.50
20 +	$3.40
50 +	$3.25
100 +	$3.09
Information
Bmotorsports Part #	CONN-100805
Availability	In Stock
Shipping Weight	0.05 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

Denso Injector Side Connector Receptacle. Connector ONLY. Terminals not included.

This connector receptacle is the same as the connector molded into Denso injectors on millions of applications worldwide. This allows plug n play adapters to be made, breakout harnesses, and all sorts of applications previously unavailable.

This is not an OEM component as no such part is made. In the past, low quality mates were available and we avoided them due to quality problems. This high quality custom part uses genuine OEM terminals and seals and we are happy to finally make this high quality option available to the public!

Mates with Toyota # 90980-11153.

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-100451	Sumitomo HX / DL / SL Sealed Series Male terminal 18 - 16 AWG Terminal, loose piece
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Housing	CONN-100805	Denso Injector Side Connector Receptacle
Connector Kit	CONN-75973	Denso Injector Side Connector Receptacle Kit
Pigtail	CONN-85973	Denso Injector Side Connector Receptacle Pigtail
Mating Parts
Terminals	CONN-11856	Sumitomo TS / SL Female Terminal 0.5 - 1.25 mm2 ( 20 - 16 AWG )
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Housing	CONN-11660	Sumitomo 2 Way TS Plug Housing for Denso Injectors, (Toyota # 90980-11153)
Connector Kit	CONN-75971	Sumitomo 2 Way TS Plug Kit for Denso Injectors, (Toyota # 90980-11153)
Pigtail	CONN-85971	Sumitomo 2 Way TS Plug Pigtail for Denso Injectors, (Toyota # 90980-11153)
Mating Parts
Terminals	CONN-11656	Injector Connector Terminal (22 - 16 gauge) [heat resistant copper alloy]
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Housing	CONN-11655	Nippon Denso Type Injector 2 way Connector ( connector only )
Connector Kit	CONN-75572	Nippon Denso Type Injector Connector Kit
Pigtail	CONN-85572	Nippon Denso Type Injector Connector Pigtail

Applications

Denso Toyota Injector Side Connector Receptacle
Denso Lexus Injector Side Connector Receptacle
Denso Subaru Injector Side Connector Receptacle
Denso Mazda Injector Side Connector Receptacle
Denso Nissan Injector Side Connector Receptacle
Denso Mitsubishi Injector Side Connector Receptacle
Fits millions of other sensor, injector, & solenoid applications

Specifications

Parameter Value
Number of Ways 2
Gender Receptacle/Female
Terminal Size 2.3mm
Terminal Type Flat
Min. Wire Gauge 18
Max. Wire Gauge 16

Used In

Part #	Description
CONN-75973	Denso Injector Side Connector Receptacle Kit
CONN-85973	Denso Injector Side Connector Receptacle Pigtail
CONN-85976	Denso Injector Harness to EV1 Injector Adapter
CONN-85977	Denso Injector Harness to EV6/EV14 Injector Adapter
