5 Way 090II Receptacle Connector Mate Pigtail to Toyota Subaru MAF	Part # CONN-86059

Pricing
1 +	$8.99
25 +	$8.19
100 +	$7.99
Information
Bmotorsports Part #	CONN-86059
Availability	In Stock
Shipping Weight	0.002 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

5 Way 090II Receptacle Connector Mate Pigtail to Toyota Subaru MAF. A completed pigtail is provided.

This connector mates to the MAF connection allowing you to break out the air intake temperature signal to a remote IAT without cutting into the factory harness.
This connector also allows you to adapt your MAF sensor to a MAP or TMAP sensor for a true speed density conversion.

Associated & Mating Parts

Relationship	Part #	Description
Associated Connectors
Connector Only	CONN-100984	5 Way 090II Receptacle Connector Mate to Toyota Subaru MAF
Terminals	CONN-100069	Sumitomo TS Sealed Series Male Terminal, Brass/Tin ( 20 - 16 gauge )
Seals	CONN-00145	Sumitomo HM / MT / TS Sealed Series wire seal, black ( 20 - 16 gauge )
Connector Kit	CONN-76059	5 Way 090II Receptacle Connector Mate Kit to Toyota Subaru MAF
Connector Pigtail	CONN-86059	5 Way 090II Receptacle Connector Mate Pigtail to Toyota Subaru MAF
Cavity Plug	CONN-100550	Sumitomo MT / TS / HX / SL Sealed Series Cavity plug, black 7160-9465
Mating Connectors
Connector Only	CONN-100680	5 Way 090II Plug Assembly for Subaru & Toyota MAF (Connector + Lock)
Terminals	CONN-11856	Sumitomo TS / SL Female Terminal 0.5 - 1.25 mm2 ( 20 - 16 AWG )
Seals	CONN-00145	Sumitomo HM / MT / TS Sealed Series wire seal, black ( 20 - 16 gauge )
Connector Kit	CONN-75825	5 Way Plug Kit for Subaru & Toyota MAF
Connector Pigtail	CONN-85825	5 Way Plug Pigtail for Subaru & Toyota MAF

Applications

Applications:

Toyota MAF mate found on many vehicles 1994-2005
Subaru MAF mate found on many vehicles 1999-2004
Many other Applications not listed

Specifications

Parameter Value
Number of Ways 5
Gender Receptacle/Female
Terminal Size 2.3mm
Terminal Type Flat
Min. Wire Gauge 20
Max. Wire Gauge 16

This product contains the following items:
	» 25 x Labor $0.25/minute Part # LABR-00001
	» 5 x 18AWG Automotive TXL Wire Black Part # WIRE-00459s
	» 5 x Sumitomo HM / MT / TS Sealed Series wire seal, black ( 20 - 16 gauge ) Part # CONN-00145
	» 5 x Sumitomo TS Sealed Series Male Terminal, Brass/Tin ( 20 - 16 gauge ) Part # CONN-100069
	» 1 x 5 Way 090II Receptacle Connector Mate to Toyota Subaru MAF Part # CONN-100984
