GM Delphi / Packard - LS Engine Coil Bank Extender Harness Part # CONN-85751
GM Delphi / Packard - LS Engine Coil Bank Extender Harness GM Delphi / Packard - LS Engine Coil Bank Extender Harness GM Delphi / Packard - LS Engine Coil Bank Extender Harness GM Delphi / Packard - LS Engine Coil Bank Extender Harness GM Delphi / Packard - LS Engine Coil Bank Extender Harness
Pricing
1 + $21.99
5 + $21.49
10 + $20.99
25 + $20.49
50 + $19.99
100 + $19.49
250 + $18.49
Information
Bmotorsports Part # CONN-85751
Availability In Stock
Shipping Weight 0.1 Lbs.
Shipping Location VA   (Shipping Info)
Options
Length
Ship Estimator Quantity:

Description

GM Delphi / Packard - LS Engine Coil Bank Extender Harness


Associated & Mating Parts

Relationship Part # Description
Associated Parts
Terminals CONN-56256GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Female Terminal ( 20 - 16 gauge )
Seals CONN-56058GM Delphi / Packard - Metripack 150 2.85-2.03mm Cable Seal, Dark Red - 18-14 AWG
Connector Assembly CONN-52359GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed male assembly for main coil bank connector, gray
Connector Kit CONN-75594GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed male assembly Connector Kit for main coil bank connector, gray
Pigtail CONN-85594GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed male assembly for main coil bank connector Pigtail, gray
Associated Parts
Terminals CONN-56260GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Male Terminal ( 20 - 16 gauge )
Seals CONN-56058GM Delphi / Packard - Metripack 150 2.85-2.03mm Cable Seal, Dark Red - 18-14 AWG
Connector Assembly CONN-52360GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed female assembly for main coil bank connector, gray
Connector Kit CONN-75599GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed female assembly Kit for main coil bank connector, gray
Pigtail CONN-85599GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed female pigtail for main coil bank connector, gray
Extension
Extension CONN-85751GM Delphi / Packard - LS Engine Coil Bank Extender Harness
Pair Kit
Connector Pair Kit CONN-200052GM Delphi / Packard - 8-way (1 blocked) Metripack 150 sealed connector pair

Specifications

Parameter Value
Number of Ways7
Terminal Size1.5mm
Min. Wire Gauge20
Max. Wire Gauge16

This product contains the following items:
Labor $0.25/minute» 30 x Labor $0.25/minute
Part # LABR-00001
16AWG Automotive TXL Wire Black» 7 x 16AWG Automotive TXL Wire Black
Part # WIRE-00460s
GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Female Terminal ( 20 - 16 gauge )» 7 x GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Female Terminal ( 20 - 16 gauge )
Part # CONN-56256
GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Male Terminal ( 20 - 16 gauge )» 7 x GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Male Terminal ( 20 - 16 gauge )
Part # CONN-56260
GM Delphi / Packard - Metri-Pack 150 (Metripack) Cable Seal ( 20 - 16 gauge ), white» 14 x GM Delphi / Packard - Metri-Pack 150 (Metripack) Cable Seal ( 20 - 16 gauge ), white
Part # CONN-56057
GM Delphi / Packard - CPA for Metri-Pack ( Metripack ) 150 connectors» 1 x GM Delphi / Packard - CPA for Metri-Pack ( Metripack ) 150 connectors
Part # CONN-02059
1/2 in. Diameter x 4ft. Black 3:1 Adhesive Lined Polyolefin Heat Shrink Tubing, 110 C» 1 x 1/2 in. Diameter x 4ft. Black 3:1 Adhesive Lined Polyolefin Heat Shrink Tubing, 110 C
Part # WIRE-56259
GM Delphi / Packard - TPA for 8 way metripack 150 sealed male assembly for main coil bank connector, gray» 1 x GM Delphi / Packard - TPA for 8 way metripack 150 sealed male assembly for main coil bank connector, gray
Part # CONN-52356
GM Delphi / Packard - TPA for 8 way metripack 150 sealed female assembly for main coil bank connector, black» 1 x GM Delphi / Packard - TPA for 8 way metripack 150 sealed female assembly for main coil bank connector, black
Part # CONN-52358
Insultherm Hi-Temp braided sleeving - 3/8 inch» 1 x Insultherm Hi-Temp braided sleeving - 3/8 inch
Part # WIRE-63556
GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed female connector for main coil bank, gray» 1 x GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed female connector for main coil bank, gray
Part # CONN-52357
GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed male connector for main coil bank, gray» 1 x GM Delphi / Packard - 8 way (1 blocked) metripack 150 sealed male connector for main coil bank, gray
Part # CONN-52355
