3 Way Receptacle pigtail for Japanese coils & sensors	Part # CONN-85759

Pricing
1 +	$9.49
25 +	$9.25
50 +	$8.99
100 +	$7.49
400 +	$6.99
Information
Bmotorsports Part #	CONN-85759
Availability	In Stock
Shipping Weight	0.15 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

3 Way Receptacle pigtail for Japanese coils & sensors

For use on Japanese applications for ignition coils & sensor connectors.

Seals: CONN-00119
Terminals: CONN-100451

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Connector Housing	CONN-100450	3 Way Receptacle for Japanese coils & sensors
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Terminals	CONN-100451	Sumitomo HX / DL / SL Sealed Series Male terminal 18 - 16 AWG Terminal, loose piece
Connector Kit	CONN-75759	3 Way Receptacle kit for Japanese coils & sensors
Connector Pigtail	CONN-85759	3 Way Receptacle pigtail for Japanese coils & sensors
Mating Parts
Connector Housing	CONN-100449	3 Way Plug for Japanese coils & sensors
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Terminals	CONN-100452	Sumitomo HX / DL / SL Sealed Series Female terminal 18 - 16 AWG Terminal, loose piece
Connector Kit	CONN-75758	3 Way Plug kit for Japanese coils & sensors
Connector Pigtail	CONN-85758	3 Way Plug pigtail for Japanese coils & sensors

Specifications

Parameter Value
Number of Ways 3
Gender Receptacle/Female
Terminal Size 2.3mm
Terminal Type Flat
Min. Wire Gauge 20
Max. Wire Gauge 16

Applications:

Part Compatibility

The following is a list of reported vehicle applications. This data is not a comprehensive listing nor guaranteed to be accurate. If you are aware of a vehicle application that is not listed or have a correction to submit please email us at sales@bmotorsports.com so that we may include it in our listings.

Year Start Year End Make Model Trim Engine Code

1999 2003 Lexus RX300 1MZ-FE

This product contains the following items:
	» 15 x Labor $0.25/minute Part # LABR-00001
	» 3 x 16AWG Automotive TXL Wire Black Part # WIRE-00460s
	» 3 x Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG) Part # CONN-00119
	» 1 x 3 Way Receptacle for Japanese coils & sensors Part # CONN-100450
	» 3 x Sumitomo HX / DL / SL Sealed Series Male terminal 18 - 16 AWG Terminal, loose piece Part # CONN-100451
