Home » Shop » Coil Connectors » 4 Way Connector Plug Kit for Bosch Coils & Sensors VW# 1J0973704

4 Way Connector Plug Kit for Bosch Coils & Sensors VW# 1J0973704	Part # CONN-75920

Pricing
1 +	$13.99
25 +	$12.99
100 +	$11.99
1000 +	Call for Pricing
Information
Bmotorsports Part #	CONN-75920
Availability	In Stock
Shipping Weight	0.075 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

4 Way Connector Plug Kit for Bosch Coils & Sensors VW# 1J0973704. Connector Kit. Terminals and seals ARE included.

1.5mm Terminal Blade System. Used on other a wide variety of applications for oxygen sensors, ignition coils, and other uses.

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Connector Only	CONN-100830	4 Way Connector Plug for Bosch Coils & Sensors VW# 1J0973704
Terminals	CONN-00194	Terminals for Bosch 6-way wide flat connector for LSU 4.0 sensor
Seals	CONN-00193	Seals for Bosch wide flat connector for LSU 4.0 and LSU 4.9 sensor
Connector Kit	CONN-75920	4 Way Connector Plug Kit for Bosch Coils & Sensors VW# 1J0973704
Connector Pigtail	CONN-85920	4 Way Connector Plug Pigtail for Bosch Coils & Sensors VW# 1J0973704
Mating Parts
Connector Only	CONN-100831	4 Way Connector Receptacle for Bosch Coils & Sensors, 1.5mm
Terminals	CONN-00196	Male Terminals for Bosch LSU 4.9 Receptacle Connector
Seals	CONN-00193	Seals for Bosch wide flat connector for LSU 4.0 and LSU 4.9 sensor
Connector Kit	CONN-75921	4 Way Connector Receptacle Kit for Bosch Coils & Sensors, 1.5mm
Connector Pigtail	CONN-85921	4 Way Connector Receptacle Pigtail for Bosch Coils & Sensors, 1.5mm
Extension
Extension	CONN-85922	4 Way Connector Extension for Bosch Coils & Sensors, 1.5mm

Applications

Applications:

Many ignition coils on VW, Audi, BMW, Mercedes applications
Many oxygen sensors on VW, Audi, BMW, Mercedes applications
Cummins 2003 to 2007 5.9L intake air temperature sensors 4984570 and 68430063AA

Specifications

Parameter Value
Number of Ways 4
Gender Plug/Male
Terminal Size 1.5mm
Terminal Type Flat
Min. Wire Gauge 20
Max. Wire Gauge 16

This product contains the following items:
	» 5 x Terminals for Bosch 6-way wide flat connector for LSU 4.0 sensor Part # CONN-00194
	» 5 x Seals for Bosch wide flat connector for LSU 4.0 and LSU 4.9 sensor Part # CONN-00193
	» 1 x 4 Way Connector Plug for Bosch Coils & Sensors VW# 1J0973704 Part # CONN-100830
