NTK LZA03 to NTK 24300 Lambda Sensor Adapter Part # CONN-85735
NTK LZA03 to NTK 24300 Lambda Sensor Adapter NTK LZA03 to NTK 24300 Lambda Sensor Adapter NTK LZA03 to NTK 24300 Lambda Sensor Adapter NTK LZA03 to NTK 24300 Lambda Sensor Adapter NTK LZA03 to NTK 24300 Lambda Sensor Adapter
Pricing
1 + $39.99
5 + $38.99
25 + $37.99
50 + $36.99
250 + $34.99
Information
Bmotorsports Part # CONN-85735
Availability In Stock
Shipping Weight 0.25 Lbs.
Shipping Location VA   (Shipping Info)
Ship Estimator Quantity:

Description

  • NTK LZA03 to NTK 24300 Lambda Sensor Adapter
  • Allows use of the NTK 24300 Oxygen Sensor in systems that normally require the LZA03-E1 Sensor.
  • Allows use of the NTK Sensors equipped with the Gray Connector in systems that normally require the Black Connector
  • USE WITH CAUTION. Use of the wrong sensor for systems expecting the LZA03 sensor can cause controller failure and/or incorrect readings, check with us to validate your application if you are unsure.
  • inverse of this is CONN-86010


Mating Parts


Specifications

Parameter Value
Number of Ways8
Terminal Size2.3mm
Terminal Size (Secondary)1.8mm
Min. Wire Gauge22
Max. Wire Gauge16

This product contains the following items:
Labor $0.25/minute» 30 x Labor $0.25/minute
Part # LABR-00001
Injector Connector Terminal (22 - 16 gauge) [heat resistant copper alloy]» 7 x Injector Connector Terminal (22 - 16 gauge) [heat resistant copper alloy]
Part # CONN-11656
1/2 in. Diameter x 4ft. Black 3:1 Adhesive Lined Polyolefin Heat Shrink Tubing, 110 C» 1 x 1/2 in. Diameter x 4ft. Black 3:1 Adhesive Lined Polyolefin Heat Shrink Tubing, 110 C
Part # WIRE-56259
18AWG Automotive Teflon Mil-Spec Wire Black» 7 x 18AWG Automotive Teflon Mil-Spec Wire Black
Part # WIRE-00489s
Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)» 14 x Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Part # CONN-00119
Sumitomo MT / TS / HW / HX / DL / SL Sealed Series Cavity plug, brown, Toyota # 90980–09229» 2 x Sumitomo MT / TS / HW / HX / DL / SL Sealed Series Cavity plug, brown, Toyota # 90980–09229
Part # CONN-00130
Econoseal J Series Male Terminals, 0.5mm2 - 1.4mm2 ( 20 - 16 AWG )» 7 x Econoseal J Series Male Terminals, 0.5mm2 - 1.4mm2 ( 20 - 16 AWG )
Part # CONN-100005
Insultherm Hi-Temp braided sleeving - 3/8 inch» 1 x Insultherm Hi-Temp braided sleeving - 3/8 inch
Part # WIRE-63556
8 way connector Mate to NGK / NTK Connector to adapt Bosch LSU Sensor for NGK Powerdex AFX» 1 x 8 way connector Mate to NGK / NTK Connector to adapt Bosch LSU Sensor for NGK Powerdex AFX
Part # CONN-00122
Retainer for Mate to NGK / NTK Connector to adapt Bosch LSU Sensor for NGK Powerdex AFX» 1 x Retainer for Mate to NGK / NTK Connector to adapt Bosch LSU Sensor for NGK Powerdex AFX
Part # CONN-00123
8 Way Econoseal J Series Mark II+ Receptacle Housing Connector» 1 x 8 Way Econoseal J Series Mark II+ Receptacle Housing Connector
Part # CONN-100034
Lockplate / TPA 8 Way Econoseal J Series Mark II+ Receptacle Housing Connector» 1 x Lockplate / TPA 8 Way Econoseal J Series Mark II+ Receptacle Housing Connector
Part # CONN-100035
