2 Way Receptacle Connector MT Sealed Series for Sensor Application, Blue Keyway 1	Part # CONN-100074

Pricing
1 +	$6.99
5 +	$6.75
25 +	$6.49
50 +	$6.25
100 +	$5.99
1000 +	$2.99
Information
Bmotorsports Part #	CONN-100074
Availability	In Stock
Shipping Weight	0.025 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

2 Way Receptacle Connector MT Sealed Series for Sensor Application, Blue Keyway 1. Connector ONLY. Terminals not included.

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-00115	Sumitomo 16-22 gauge brass/tin male terminal for 8 way receptacle
Seals	CONN-00145	Sumitomo HM / MT / TS Sealed Series wire seal, black ( 20 - 16 gauge )
Connector Housing	CONN-100074	2 Way Receptacle Connector MT Sealed Series for Sensor Application, Blue Keyway 1
Connector Kit	CONN-75746	2 Way Receptacle Connector Kit MT Sealed Series for Sensor Application, Blue Keyway 1
Connector Pigtail	CONN-85746	2 Way Receptacle Connector Pigtail MT Sealed Series for Sensor Application, Blue Keyway 1
Alternate Associated Parts
Terminals	CONN-100069	Sumitomo TS Sealed Series Male Terminal, Brass/Tin ( 20 - 16 gauge )
Seals	CONN-00145	Sumitomo HM / MT / TS Sealed Series wire seal, black ( 20 - 16 gauge )
Connector Housing	CONN-100072	2 Way TS Series Receptacle Connector
Connector Kit	CONN-76002	2 Way TS Series Receptacle Connector Kit
Connector Pigtail	CONN-86002	2 Way TS Series Receptacle Connector Pigtail
Mating Parts
Terminals	CONN-11856	Sumitomo TS / SL Female Terminal 0.5 - 1.25 mm2 ( 20 - 16 AWG )
Seals	CONN-00145	Sumitomo HM / MT / TS Sealed Series wire seal, black ( 20 - 16 gauge )
Connector Housing	CONN-100308	2 Way Connector Plug TS Sealed Series for Sensor Application, Gray Keyway 1
Connector Kit	CONN-75734	2 Way Connector Plug Kit TS Sealed Series for Sensor Application, Gray Keyway 1
Connector Pigtail	CONN-85734	2 Way Connector Plug Pigtail TS Sealed Series for Sensor Application, Gray Keyway 1

Applications

Boost Control Solenoid on Many Japanese applications (Sensor Side)
Pressure Control Solenoid on Many Japanese applications (Sensor Side)
Solenoid on Many Japanese applications (Sensor Side)
Sensor on Many Japanese applications (Sensor Side)

Specifications

Parameter Value
Number of Ways 2
Gender Receptacle/Female
Terminal Size 2.3mm
Terminal Type Flat
Min. Wire Gauge 20
Max. Wire Gauge 16

Used In

Part #	Description
CONN-75746	2 Way Receptacle Connector Kit MT Sealed Series for Sensor Application, Blue Keyway 1
CONN-85746	2 Way Receptacle Connector Pigtail MT Sealed Series for Sensor Application, Blue Keyway 1
