Description

Toyota & Mazda 6 Way TPS Connector, Black (connector only) - 90980-11858. Connector and Lock ONLY. Terminals and seals not included. This connector is used on many Japanese vehicles as a Throttle Body connector, Throttle Postion Sensor Connector, Ignition connector, and other applications. 2006-2009 Honda S2000. Throttle Position Sensor on some Polaris RZR 1000.

Toyota # 90980-11858
Nissan # 11858W9A6F-BYZ WTS090F-M
Associated Subaru Part Numbers: 16112AA090, 16112AA110, 16112AA170, 22633AA151, 22633AA15B, 83321AA000, 83321AE00A

Compatible Cars:
2004-2021 Forester, 2004-2013 Forester XT, 2004-2021 STI, 2005-2021 Impreza, 2005-2019 Legacy, 2005-2019 Outback, 2006-2014 WRX, 2013-2021 BRZ

Associated & Mating Parts

Specifications

Parameter	Value
Number of Ways	6
Gender	Plug/Male
Terminal Size	2.3mm
Terminal Type	Flat
Min. Wire Gauge	20
Max. Wire Gauge	16

Part Compatibility

The following is a list of reported vehicle applications. This data is not a comprehensive listing nor guaranteed to be accurate. If you are aware of a vehicle application that is not listed or have a correction to submit please email us at sales@bmotorsports.com so that we may include it in our listings.

Year Start	Year End	Make	Model	Trim	Engine Code
2006	2009	Honda	S2000		F22C1
