Home » Shop » Connectors / Harnesses » Tyco / AMP » 2 Way Sensor Plug Connector Kit, Gray

2 Way Sensor Plug Connector Kit, Gray	Part # CONN-75865

Pricing
1 +	$5.99
5 +	$5.75
25 +	$5.49
50 +	$5.25
100 +	$4.99
1000 +	Call for Pricing
Information
Bmotorsports Part #	CONN-75865
Availability	In Stock
Shipping Weight	0.05 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

2 Way Sensor Plug Connector Kit, Gray. Terminals and seals ARE included.

Frequently used on temperature sensors for Japanese vehicles. Often Toyota.

Associated & Mating Parts

Relationship	Part #	Description
Associate Connector
Terminals	CONN-00127	Terminals for Econoseal J Series Mark II+ Plug Housings, 20-16AWG
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Only	CONN-100725	2 Way Sensor Plug, Gray
Connector Kit	CONN-75865	2 Way Sensor Plug Connector Kit, Gray
Connector Pigtail	CONN-85865	2 Way Sensor Plug Connector Pigtail, Gray
Mating Connector
Terminals	CONN-100005	Econoseal J Series Male Terminals, 0.5mm2 - 1.4mm2 ( 20 - 16 AWG )
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Only	CONN-101205	2 Way Sensor Connector Receptacle Assembly, Gray
Connector Kit	CONN-76156	2 Way Sensor Receptacle Connector Kit, Gray
Connector Pigtail	CONN-86156	2 Way Sensor Receptacle Connector Pigtail, Gray

Applications

Specifications

Parameter Value
Number of Ways 2
Gender Plug/Male
Terminal Size 1.8mm
Terminal Type Flat
Min. Wire Gauge 20
Max. Wire Gauge 16

This product contains the following items:
	» 3 x Terminals for Econoseal J Series Mark II+ Plug Housings, 20-16AWG Part # CONN-00127
	» 3 x Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG) Part # CONN-00119
	» 1 x 2 Way Sensor Plug, Gray Part # CONN-100725
