4 Way Connector Plug Pigtail for C7 Corvette oxygen sensor, Black	Part # CONN-85886

Pricing
1 +	$15.99
25 +	$15.49
100 +	$14.99
1000 +	Call for Pricing
Information
Bmotorsports Part #	CONN-85886
Availability	In Stock
Shipping Weight	0.05 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

4 Way Connector Plug Pigtail for C7 Corvette oxygen sensor, Black. Connector Pigtail. Preassembled and includes connector, seals, and terminals already crimped on 12 inch wire leads. A completed pigtail is provided.

Used on other LT1 & GM & Chevy applications as the upstream or downstream oxygen sensor connection.

Associated & Mating Parts

Relationship	Part #	Description
Associated Connectors
Connector Only	CONN-100775	4 Way Connector Plug for C7 Corvette oxygen sensor, Black
Terminals	CONN-100713	Female Terminal for C7 Corvette oxygen sensor Connector Plug 20-18AWG (0.5 - 0.8mm2)
Seals	CONN-100715	Seal for C7 Corvette oxygen sensor Connectors 26-16AWG (0.22 - 1.0mm2)
Connector Kit	CONN-75886	4 Way Connector Plug Kit for C7 Corvette oxygen sensor, Black
Connector Pigtail	CONN-85886	4 Way Connector Plug Pigtail for C7 Corvette oxygen sensor, Black
Mating Connectors
Connector Only	CONN-100776	4 Way Connector Receptacle for C7 Corvette oxygen sensor, Black
Terminals	CONN-100714	Male Terminal for C7 Corvette oxygen sensor Connector Receptacle 20-18AWG (0.5 - 0.8mm2)
Seals	CONN-100715	Seal for C7 Corvette oxygen sensor Connectors 26-16AWG (0.22 - 1.0mm2)
Connector Kit	CONN-75887	4 Way Connector Receptacle Kit for C7 Corvette oxygen sensor, Black
Connector Pigtail	CONN-85887	4 Way Connector Receptacle Pigtail for C7 Corvette oxygen sensor, Black
Extension
Extension	CONN-85888	4 Way Connector Extension for C7 Corvette oxygen sensor, Black

Applications

Applications:

2014, 2015, 2016 Corvette Oxygen Sensor
Chevy LT1 Oxygen Sensor
2013 VW Jetta 2.0 Turbo 3 Bar TMAP Sensor
2017-18 Polaris RZR 1000 Turbo 3 Bar TMAP Sensor

Specifications

Parameter Value
Number of Ways 4
Gender Plug/Male
Terminal Size 1.2mm
Terminal Type Flat
Min. Wire Gauge 20
Max. Wire Gauge 18

This product contains the following items:
	» 4 x 20AWG Automotive TXL Wire Black Part # WIRE-00458S
	» 20 x Labor $0.25/minute Part # LABR-00001
	» 4 x Female Terminal for C7 Corvette oxygen sensor Connector Plug 20-18AWG (0.5 - 0.8mm2) Part # CONN-100713
	» 4 x Seal for C7 Corvette oxygen sensor Connectors 26-16AWG (0.22 - 1.0mm2) Part # CONN-100715
	» 1 x 4 Way Connector Plug for C7 Corvette oxygen sensor, Black Part # CONN-100775
