4 Way Ford / Mazda MAP Pressure Sensor Extension Part # CONN-85877
4 Way Ford / Mazda MAP Pressure Sensor Extension 4 Way Ford / Mazda MAP Pressure Sensor Extension 4 Way Ford / Mazda MAP Pressure Sensor Extension 4 Way Ford / Mazda MAP Pressure Sensor Extension 4 Way Ford / Mazda MAP Pressure Sensor Extension
Pricing
1 + $16.99
50 + $15.99
100 + $14.99
1000 + Call for Pricing
Information
Bmotorsports Part # CONN-85877
Availability In Stock
Shipping Weight 0.017 Lbs.
Shipping Location VA   (Shipping Info)
Options
Length
Ship Estimator Quantity:

Description

4 Way Ford / Mazda MAP Pressure Sensor Extension. Connector Extension. Available in 12, 24, 36in lengths.

Connects to the Bosch sensor sometimes also referred to as the Bosch TMAP Sensor due to the additional of a temperature sensor combined with the MAP sensor. Specific to Ford & Mazda vehicles, not for other platforms. Applications Include:

  • Mazdaspeed 3
  • Mazdaspeed 6
  • Mazda CX-7


Associated & Mating Parts

Relationship Part # Description
Associated Parts
Connector Only CONN-100720Mate to 4 Way Ford / Mazda MAP Pressure Sensor Connector
Terminals CONN-56260GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Male Terminal ( 20 - 16 gauge )
Seals CONN-56057GM Delphi / Packard - Metri-Pack 150 (Metripack) Cable Seal ( 20 - 16 gauge ), white
Connector Kit CONN-75851Mate to 4 Way Ford / Mazda MAP Pressure Sensor Connector Kit
Connector Pigtail CONN-85851Mate to 4 Way Ford / Mazda MAP Pressure Sensor Connector Pigtail
Connector Only CONN-1007044 Way Ford / Mazda MAP Pressure Sensor Connector
Terminals CONN-100481Ford / Yazaki 1.5 Terminal, 18-16AWG
Seals CONN-56057GM Delphi / Packard - Metri-Pack 150 (Metripack) Cable Seal ( 20 - 16 gauge ), white
Connector Kit CONN-758564 Way Ford / Mazda MAP Pressure Sensor Connector Kit
Connector Pigtail CONN-858564 Way Ford / Mazda MAP Pressure Sensor Connector Pigtail
Extension
Ford / Mazda TMAP Extension CONN-858774 Way Ford / Mazda MAP Pressure Sensor Extension
Adapters
Ford / Mazda TMAP to Bosch TMAP Adapter CONN-85824Ford / Mazda TMAP to Bosch TMAP Adapter

Specifications

Parameter Value
Number of Ways4
Terminal Size1.5mm
Terminal TypeFlat
Min. Wire Gauge20
Max. Wire Gauge16

This product contains the following items:
Labor $0.25/minute» 40 x Labor $0.25/minute
Part # LABR-00001
18AWG Automotive TXL Wire Black» 4 x 18AWG Automotive TXL Wire Black
Part # WIRE-00459s
GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Male Terminal ( 20 - 16 gauge )» 4 x GM Delphi / Packard - Sealed Metri-Pack 150 ( Metripack ) Male Terminal ( 20 - 16 gauge )
Part # CONN-56260
GM Delphi / Packard - Metri-Pack 150 (Metripack) Cable Seal ( 20 - 16 gauge ), white» 8 x GM Delphi / Packard - Metri-Pack 150 (Metripack) Cable Seal ( 20 - 16 gauge ), white
Part # CONN-56057
1/2in. Diameter Clean Cut Expandable Braided Sleeving, Black» 1 x 1/2in. Diameter Clean Cut Expandable Braided Sleeving, Black
Part # WIRE-57558
Mate to 4 Way Ford / Mazda MAP Pressure Sensor Connector» 1 x Mate to 4 Way Ford / Mazda MAP Pressure Sensor Connector
Part # CONN-100720
Ford / Yazaki 1.5 Terminal, 18-16AWG» 4 x Ford / Yazaki 1.5 Terminal, 18-16AWG
Part # CONN-100481
4 Way Ford / Mazda MAP Pressure Sensor Connector» 1 x 4 Way Ford / Mazda MAP Pressure Sensor Connector
Part # CONN-100704
