Description

12 Way Allison 1k/2k/2400 2003.5+ Transmission Gear Selector Switch / Range / PNP / PRNDL / Neutral Safety Switch Pigtail. Connector Pigtail. A completed pigtail with 12 inch wire leads is provided. Made in USA.

Standard length is 12 inches, if you need something longer or shorter please call us and let us know you need them longer for a fee, If needing longer wires, do note that the wire color is subject to change. This gear selector pigtail is a 12 way mixed connector with two GT 280 positions and and ten GT 150. One GT 150 position is blocked and 1 sealed with a cavity plug. As provided, it is a 10 wire pigtail. We can also build this in a 7 wire version to fit the new GM selector sensor on older transmissions or other quantity by request.

This gear selector switch connector pigtail is used with 4L60E 4L65E 4L70E 2004+, 4L80E 4L85E 2001+, 1K/2K and 2400 Allison Transmissions (after 2003.5), GM gear selector switches mounted on the side of the transmission case. Neutral Start Back Up Switch - 12 Way 1k/2k/2400 after July 1/03.
If you are performing a swap or a conversion and you are not sure, please let us know and we can provide the appropriate parts.
Used on millions of GM applications using the 2004+ 4L60e, 2001+ 4L80e, 4L70e, 1000 / 2000 / 2400 Allison transmissions.

Associated & Mating Parts

Applications

Applications:

• When used as a 7 wire version, ACDelco Pigtail PT1706 equivalent
• Fits Range selector switch part numbers GM# 24221125, 29541852
• Fits Range selector switch part numbers ACDelco # D2259C D2262C D74410B
• Fits Range selector switch part numbers SMP# NS-319 NS-331 NS319 NS331 NS377 NS-377
• Fits Range selector switch part numbers Duralast# DR4146
• Pigtail version of St. Clair # 300228
• fits some International trucks gear selector switch on transmissions

Specifications

Parameter	Value
Number of Ways	12
Gender	Plug/Male
Terminal Size	2.8mm
Terminal Type	Flat
