Genuine Delphi / GM 3 Bar Style Map Sensor - 12223861 - 16040749 (96pc case buy only) Part # SNSR-03075
Genuine Delphi / GM 3 Bar Style Map Sensor - 12223861 - 16040749 (96pc case buy only)
Pricing
1 + $49.99
96 + $49.99
Information
Bmotorsports Part # SNSR-03075
Availability Special Order
Shipping Weight 0.15 Lbs.
Shipping Location VA   (Shipping Info)
Ship Estimator Quantity:

Description

Genuine Delphi / GM 3 Bar Style Map Sensor - 12223861 - 16040749 (96pc case buy only)

Due to a change in our product lineup, we will continue to stock the Genuine Delphi part (SNSR-03075) as a case quantity only purchase and will be stocking a US Made 3 bar GM / Delphi MAP Sensor (SNSR-03074 in our standard price breaks). The SNSR-03074, US Made 3 bar MAP Sensor has the same calibration as SNSR-03075 and meets or exceeds all Delphi specifications.


Specifications

3 bar GM style map sensor 12223861 - 16040749 rating chart


3 bar GM style map sensor 12223861 - 16040749 output voltage ( Vout ) chart
3 bar GM style map sensor 12223861 - 16040749 output voltage ( Vout ) chart


Mating Parts

Mating Sensor Connector Pigtail:

Mating Sensor Connector Kit: Mating Connector: Terminals: Seals:


Images / Drawings

3 bar GM style map sensor 12223861 - 16040749 Mounting diagram chart
