Ford/Mazda/GM 6 Way with keyway for DBW Throttle Body Connector Plug Pigtail Part # CONN-86080
Ford/Mazda/GM 6 Way with keyway for DBW Throttle Body Connector Plug Pigtail Ford/Mazda/GM 6 Way with keyway for DBW Throttle Body Connector Plug Pigtail Ford/Mazda/GM 6 Way with keyway for DBW Throttle Body Connector Plug Pigtail
Pricing
1 + $13.49
25 + $12.99
50 + $12.49
100 + $11.99
1000 + $10.99
Information
Bmotorsports Part # CONN-86080
Availability In Stock
Shipping Weight 0.05 Lbs.
Shipping Location VA   (Shipping Info)
Ship Estimator Quantity:

Description

Ford/Mazda/GM 6 Way with keyway for DBW Throttle Body Connector Plug Pigtail. Preassembled and includes connector, front lock, seals, and terminals already crimped on 12 inch wire leads. A completed pigtail is provided. Equivalent of Ford WPT-1063. Equivalent GM Service Connector# 13586581.

Used on a wide variety of Ford TPS/ E-throttle & Mazda DBW Throttle applications.


Associated & Mating Parts

Relationship Part # Description
Associated Connectors
Connector Only CONN-101007Ford/Mazda/GM 6 Way with keyway for DBW Throttle Body Connector Plug
Terminals CONN-100698Ford/Mazda 6 Way MAF Connector Female Terminal, Tin, 20-18AWG (0.35 - 0.5mm2)
Connector Kit CONN-76080Ford/Mazda/GM 6 Way with keyway for DBW Throttle Body Connector Plug Kit
Connector Pigtail CONN-86080Ford/Mazda/GM 6 Way with keyway for DBW Throttle Body Connector Plug Pigtail
Mating Connectors
Connector Only CONN-100716Receptacle Connector Mate to Ford/Mazda 6 Way MAF Plug
Terminals CONN-100861Tin Plate Male Terminal for Mate to Ford/Mazda 6 Way MAF Connector, 20-18AWG (0.5 - 0.75mm2)
Connector Kit CONN-75841
Connector Pigtail CONN-85841
Extensions
Ford/Mazda 6 Way MAF Harness Extension CONN-861943 Way Plug Connector Pigtail for BMW Sensors

Applications

Applications:

  • Equivalent GM Service Connector# 13586581
  • GM LT1 DBW Connector
  • GM LT4 DBW Connector
  • GM LT5 DBW Connector
  • WPT-1063
  • Some Ford MAF
  • Some Mazda MAF
  • Ford Fiesta MAF
  • Ford Fusion MAF
  • Ford Mustang MAF (2005+)


Specifications

Parameter Value
Number of Ways6
GenderPlug/Male
Terminal Size1mm
Terminal TypeFlat
Min. Wire Gauge20
Max. Wire Gauge18

This product contains the following items:
Labor $0.25/minute» 30 x Labor $0.25/minute
Part # LABR-00001
18AWG Automotive TXL Wire Black» 6 x 18AWG Automotive TXL Wire Black
Part # WIRE-00459s
Ford/Mazda 6 Way MAF Connector Female Terminal, Tin, 20-18AWG (0.35 - 0.5mm2)» 6 x Ford/Mazda 6 Way MAF Connector Female Terminal, Tin, 20-18AWG (0.35 - 0.5mm2)
Part # CONN-100698
Ford/Mazda/GM 6 Way with keyway for DBW Throttle Body Connector Plug» 1 x Ford/Mazda/GM 6 Way with keyway for DBW Throttle Body Connector Plug
Part # CONN-101007
