4 Way Low Keyway Nissan Oxygen Sensor Connector Extension for 370Z, Titan	Part # CONN-86124

Pricing
1 +	$39.99
Information
Bmotorsports Part #	CONN-86124
Availability	In Stock
Shipping Weight	0.005 Lbs.
Shipping Location	VA (Shipping Info)
Options
Harness Length
	Quantity:

Description

4 Way Low Keyway Nissan Oxygen Sensor Connector Extension for 370Z, Titan. Connector extension. Standard lengths are offered with high-temp fiberglass composition sleeving.

This connector is the oxygen sensor device side connection for many newer Nissan Vehicles, including the 2013-2019 Titan and 370Z

Associated & Mating Parts

Relationship	Part #	Description
Associated Connectors
Connector Only	CONN-101143	4 Way Nissan RH Receptacle Connector for 370Z, Titan Oxygen Sensor with Low Keyway, RH04MDGY-P
Terminals	CONN-100654	Nissan MAF Male Terminal 20AWG (.5mm2)
Seals	CONN-100655	Nissan MAF Seal 20-18AWG (.5mm2-0.85mm2)
Connector Kit	CONN-76123	4 Way Nissan RH Receptacle Connector Kit for 370Z, Titan Oxygen Sensor with Low Keyway, RH04MDGY-P
Connector Pigtail	CONN-86123	4 Way Nissan RH Receptacle Connector Pigtail for 370Z, Titan Oxygen Sensor with Low Keyway, RH04MDGY-P
Mating Connectors
Connector Only	CONN-101142	4 Way Nissan RH04FDGY-P Plug Connector for 370Z, Titan Oxygen Sensor with Low Keyway
Terminals	CONN-100719	Nissan MAF Female Terminal 20AWG (.5mm2)
Seals	CONN-100655	Nissan MAF Seal 20-18AWG (.5mm2-0.85mm2)
Connector Kit	CONN-76122	4 Way Nissan RH04FDGY-P Plug Connector Kit for 370Z, Titan Oxygen Sensor with Low Keyway
Connector Pigtail	CONN-86122	4 Way Nissan RH04FDGY-P Plug Connector Pigtail for 370Z, Titan Oxygen Sensor with Low Keyway
Extensions
Connector Extension	CONN-86124	4 Way Low Keyway Nissan Oxygen Sensor Connector Extension for 370Z, Titan

Applications

Nissan 370Z O2 Sensor Connector
Nissan Titan VK56DE Oxygen Sensor Connector
Many applications not listed

Specifications

Parameter Value
Number of Ways 4
Terminal Size 0.63mm
Terminal Type Flat
Min. Wire Gauge 20
Max. Wire Gauge 20

This product contains the following items:
	» 1 x 3/8 in. Diameter x 4ft. Black 3:1 Adhesive Lined Polyolefin Heat Shrink Tubing, 110 C Part # WIRE-56258
	» 1 x Insultherm Hi-Temp braided sleeving - 1/4 inch Part # WIRE-63555
	» 4 x Nissan MAF Female Terminal 20AWG (.5mm2) Part # CONN-100719
	» 8 x Nissan MAF Seal 20-18AWG (.5mm2-0.85mm2) Part # CONN-100655
	» 4 x Nissan MAF Male Terminal 20AWG (.5mm2) Part # CONN-100654
	» 1 x 4 Way Nissan RH04FDGY-P Plug Connector for 370Z, Titan Oxygen Sensor with Low Keyway Part # CONN-101142
	» 1 x 4 Way Nissan RH Receptacle Connector for 370Z, Titan Oxygen Sensor with Low Keyway, RH04MDGY-P Part # CONN-101143
	» 4 x 20AWG Tefzel Wire Black Part # WIRE-00058S
