LSU 4.9 Sensor Adapter to Harness with NTK Connector for AFR500( v2 & v3 )	Part # CONN-85938

Pricing
1 +	$49.99
Information
Bmotorsports Part #	CONN-85938
Availability	In Stock
Shipping Weight	0.25 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

This Adapter allows you to use a VW type LSU 4.9 Sensor with an AFR500( v2 or v3 ) whose wiring harness has an NTK Connector. Not for use with AFR500(v1) or NGK Powerdex AFX.

DO NOT USE WITH INCOMPATIBLE ELECTRONICS. This will not make your Innovate controller work with an NTK sensor, the electronics must support the NTK Sensor. Uniquely, the Ballenger Motorsports AFR500V2 is capable of this control.

If used with the AFR500( v2 or v3 ), please validate that your Jumper settings are correct for the LSU 4.9 setting! It is strongly preferred to buy the LSU 4.9 from Ballenger Motorsports (SNSR-01043) for quality & insertion loss reasons. This is however, a common request, and we try to put our customers first.

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-00195	Terminals for Bosch LSU 4.9 Connector
Seals	CONN-00193	Seals for Bosch wide flat connector for LSU 4.0 and LSU 4.9 sensor
Cavity Plug	CONN-56557	GM Delphi / Packard - GT 150 Cavity Plug, Green, 4.0mm
Connector Housing	CONN-100321	Bosch 6 way LSU 4.9 Connector
Connector Kit	CONN-75762	Bosch 6 way LSU 4.9 Connector Kit
Pigtail	CONN-85762	Bosch 6 way LSU 4.9 Connector Pigtail
Associated Parts
Connector Housing	CONN-00110	NGK / NTK 8-way Connector assembly to adapt Bosch LSU Sensor for NGK Powerdex AFX & Ballenger Motorsports AFR500 ( connector and TPA )
Terminals	CONN-00115	Sumitomo 16-22 gauge brass/tin male terminal for 8 way receptacle
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Cavity Plug	CONN-00130	Sumitomo MT / TS / HW / HX / DL / SL Sealed Series Cavity plug, brown, Toyota # 90980–09229
Connector Kit	CONN-00135	8 way NGK / NTK Connector Kit to adapt Bosch LSU Sensor for NGK Powerdex AFX & Ballenger Motorsports AFR500
Connector Pigtail	CONN-85590	NGK / NTK Pigtail to adapt Bosch LSU Sensor for NGK Powerdex AFX & Ballenger Motorsports AFR500
Mating Parts
Connector Housing	CONN-100322	Bosch 6 way LSU 4.9 Receptacle Connector
Terminals	CONN-00196	Male Terminals for Bosch LSU 4.9 Receptacle Connector
Seals	CONN-00193	Seals for Bosch wide flat connector for LSU 4.0 and LSU 4.9 sensor
Cavity Plug	CONN-56059	GM Delphi / Packard - Metri-Pack 150 (Metripack) Cavity Plug
Connector Kit	CONN-75772	Bosch 6 way LSU 4.9 Receptacle Connector Kit
Connector Pigtail	CONN-85772	Bosch 6 way LSU 4.9 Receptacle Connector Pigtail
Mating Parts
Connector Housing	CONN-00121	Mate to NGK / NTK Connector assembly to adapt Bosch LSU Sensor for NGK Powerdex AFX & Ballenger Motorsports AFR500 ( 8-way connector and TPA )
Terminals	CONN-11656	Injector Connector Terminal (22 - 16 gauge) [heat resistant copper alloy]
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Cavity Plug	CONN-00130	Sumitomo MT / TS / HW / HX / DL / SL Sealed Series Cavity plug, brown, Toyota # 90980–09229
Connector Kit	CONN-00124	Mate to NGK / NTK Connector Kit to adapt Bosch LSU Sensor for NGK Powerdex AFX & Ballenger Motorsports AFR500
Connector Pigtail	CONN-85588	Mate to NGK / NTK Pigtail to adapt Bosch LSU Sensor for NGK Powerdex AFX
LSU 4.9 Extension
Extension	CONN-85773	Bosch 6 Way LSU 4.9 Extension Harness
Mating Sensor (LSU 4.9)
Mating LSU 4.9 Sensor (0.45m)	SNSR-01042	Bosch LSU 4.9 Wideband O2 Sensor ( UEGO ) with Bosch Connector - Advanced Bosch LSU Design (.45m/17.7in length)
Mating LSU 4.9 Sensor (1m)	SNSR-01029	Bosch LSU 4.9 Wideband O2 Sensor ( UEGO ) with Bosch Connector - Advanced Bosch LSU Design (1m/39.4in length)

Applications

Specifications

Parameter Value
Terminal Size 2.3mm
Terminal Type Flat
Min. Wire Gauge 22
Max. Wire Gauge 16
