Amphenol Duramate 90° Backshell Size 24 Part # CONN-101260
Amphenol Duramate 90° Backshell Size 24 Amphenol Duramate 90° Backshell Size 24 Amphenol Duramate 90° Backshell Size 24
Pricing
1 + $8.99
Information
Bmotorsports Part # CONN-101260
Availability In Stock
Shipping Weight 0.05 Lbs.
Shipping Location VA   (Shipping Info)
Ship Estimator Quantity:

Description

Amphenol Duramate 90° Backshell Size 24
This is a snap-on version, it snaps over the wide thread adapter on the back of the connector and is free to rotate in the desired orientation.



The Amphenol Duramate connection system is perfect for use in high temperature and high vibration environments. This is a -24 shell size version.


Associated & Mating Parts

Relationship Part # Description
Replacement and Accessory Parts
Rear 90° Size 24 Backshell CONN-101260Amphenol Duramate 90° Backshell Size 24
Rear straight Size 24 Backshell CONN-101255Amphenol Duramate Threaded Straight Backshell Size 24
Flange Felt Foam Seal CONN-101251Amphenol Duramate Shell Size 24 Felt Flange Seal Only
Spring Lock Panel Washer CONN-101252Amphenol Duramate Shell Size 24 Panel Lock Washer Only
Threaded Panel Nut CONN-101253Amphenol Duramate Shell Size 24 Threaded Panel Nut Only
Associated Parts
Size 12 Female Solid Contact CONN-101100Deutsch Size 12 Solid Female Pin Terminals, 2.5mm (14 - 12 AWG)
Size 12 Male Solid Contact CONN-101101Deutsch Size 12 Solid Male Pin Terminals, 2.5mm (14 - 12 AWG)
Size 16 Female Solid Contact CONN-100358Deutsch Size 16 Solid Female Socket Terminals, 0.5-1.5mm2 (20-16 AWG)
Size 16 Male Solid Contact CONN-100357Deutsch Size 16 Solid Male Pin Terminals, 0.5-1.5mm2 (20-16 AWG)
Size 16 Female Stamped + Formed Terminal CONN-100367Deutsch Size 16 Stamped & Formed Socket Female Nickel Plated Terminal, 0.5-1mm2 (20-16AWG)
Size 16 Male Stamped + Formed Terminal CONN-100368Deutsch Size 16 Stamped & Formed Pin Male Nickel Plated Terminal, 0.5-1mm2 (20-16AWG)
Size 16 Cavity plug CONN-56158GM Delphi / Packard - Metripack 150.2 Seal Plug for hand insertion (with tail)
Bulkhead Connector Kits
19 way Duramate Bulkhead Kit CONN-200110Amphenol Duramate 19 Way Bulkhead Connector Kit
29 Way Duramate Bulkhead Kit - Reduced Seal CONN-200111Amphenol Duramate 29 Way Bulkhead Connector Kit
47 Way Duramate Bulkhead Kit - Reduced Seal CONN-200112Amphenol Duramate 47 Way Bulkhead Connector Kit
48 Way Deutsch DRB Bulkhead Kit CONN-200100Deutsch DRB 48 Way Bulkhead Connector Kit
