4 Way Delphi GT 280 GM Fuel Pump Rewire / Upgrade Pigtail	Part # CONN-86213

Pricing
1 +	$9.99
5 +	$9.49
25 +	$8.99
50 +	$8.49
Information
Bmotorsports Part #	CONN-86213
Availability	In Stock
Shipping Weight	0.05 Lbs.
Shipping Location	VA (Shipping Info)
Options
Wire Size
	Quantity:

Description

4 Way Delphi GT 280 GM Fuel Pump Rewire / Upgrade Pigtail. Connector Pigtail. A completed flying lead assembly with connector and 12" leads is provided.

Used as the GM Duramax 6.6L Diesel Injector connector. Each connector powers two injectors. If this is being used in a fuel pump application, please let us know the application so we build the pigtail with the proper wire sizes in the appropriate positions. The diagram for picture #4 is shown for retrofit kits with power and ground on pins B and D, respectively. Newer models will have ground on A and power on D. If you're not sure let us know your application.
Used for GM fuel pump rewire/upgrade kits with the OVAL connector. This replaces the old BOX style. There is one more white connector plug that is RECTANGLE shaped. Many replacement GM fuel pump tophats have this newer oval connector style on them, part numbers 1AFPU01117, Airtex WH3009.
ACDELCO PT2887 Equivalent

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-56656	GM Delphi / Packard - GT 280 Female Terminal, 18-16 gauge [.75-1.00mm2] (Tin/Brass)
Terminals	CONN-56657	GM Delphi / Packard - GT 280 Female Terminal, 16-12 gauge [1.5-3.00mm2] (Tin/Brass)
Seals	CONN-56756	GM Delphi / Packard - GT 280 1.86-2.25mm Cable Seal, Yellow - 18-16 gauge
Connector Only	CONN-101301	4 Way Delphi GT 280 Plug Connector Assembly for Duramax LBZ Diesel Injector
Connector Kit	CONN-76213	4 Way Delphi GT 280 GM Duramax LBZ Diesel Injector Plug Connector Kit
Connector Pigtail	CONN-86213	4 Way Delphi GT 280 GM Fuel Pump Rewire / Upgrade Pigtail
Mating Parts
Terminals	CONN-56660	GM Delphi / Packard - GT 280 Male Terminal, 18-16 gauge [.75-1.00mm2] (Tin/Brass)
Terminals	CONN-56661	GM Delphi / Packard - GT 280 Male Terminal, 16-12 gauge [1.50-3.00mm2] (Tin/Brass)
Seals	CONN-56756	GM Delphi / Packard - GT 280 1.86-2.25mm Cable Seal, Yellow - 18-16 gauge
Connector Only	CONN-101303	4 Way Delphi GT 280 Receptacle Connector Assembly
Connector Kit	CONN-76214	4 Way Delphi GT 280 Receptacle Connector Kit
Connector Pigtail	CONN-86214	4 Way Delphi GT 280 Receptacle Connector Pigtail

Specifications

Parameter Value
Number of Ways 4
Gender Plug/Male
Terminal Size 2.8mm
Terminal Type Flat
Min. Wire Gauge 18
Max. Wire Gauge 12

This product contains the following items:
	» 4 x 16AWG Automotive TXL Wire Black Part # WIRE-00460s
	» 4 x GM Delphi / Packard - GT 280 Female Terminal, 18-16 gauge [.75-1.00mm2] (Tin/Brass) Part # CONN-56656
	» 4 x GM Delphi / Packard - GT 280 1.86-2.25mm Cable Seal, Yellow - 18-16 gauge Part # CONN-56756
	» 1 x 4 Way Delphi GT 280 Plug Connector ONLY Part # CONN-101299
	» 1 x 4 Way Delphi GT 280 Rear TPA ONLY Part # CONN-101300
