Mate to 3 Way Honda Pencil Coil ( COP ) Receptacle Connector Kit	Part # CONN-76217

Pricing
1 +	$6.99
5 +	$6.89
25 +	$6.49
50 +	$6.29
100 +	$5.99
1000 +	$4.99
Information
Bmotorsports Part #	CONN-76217
Availability	In Stock
Shipping Weight	0.05 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

Mate to 3 Way Honda Pencil Coil ( COP ) Receptacle Connector Kit. Connector Kit. Terminals and seals are included.

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-100069	Sumitomo TS Sealed Series Male Terminal, Brass/Tin ( 20 - 16 gauge )
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Housing	CONN-101284	Mate to 3 Way Honda Pencil Coil ( COP ) Connector Receptacle Only
Connector Kit	CONN-76217	Mate to 3 Way Honda Pencil Coil ( COP ) Receptacle Connector Kit
Pigtail	CONN-86217	Mate to 3 Way Honda Pencil Coil ( COP ) Receptacle Connector Pigtail
Mating Parts
Terminals	CONN-100452	Sumitomo HX / DL / SL Sealed Series Female terminal 18 - 16 AWG Terminal, loose piece
Seals	CONN-00119	Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG)
Connector Housing	CONN-100327	3 way Honda Pencil Coil ( COP ) Connector Assembly
Connector Kit	CONN-75784	3 way Honda Pencil Coil ( COP ) Connector kit
Pigtail	CONN-85784	3 way Honda Pencil Coil ( COP ) Connector pigtail

Specifications

Parameter Value
Number of Ways 3
Gender Receptacle/Female
Terminal Size 2.3mm
Terminal Type Flat
Min. Wire Gauge 20
Max. Wire Gauge 16

Applications

Honda S2000
Many Honda & Acura applications not yet listed

This product contains the following items:
	» 4 x Sumitomo HW / HX / DL / SL Sealed Series wire seal, green (20-16 AWG) Part # CONN-00119
	» 4 x Sumitomo TS Sealed Series Male Terminal, Brass/Tin ( 20 - 16 gauge ) Part # CONN-100069
	» 1 x Mate to 3 Way Honda Pencil Coil ( COP ) Connector Receptacle Only Part # CONN-101284
