Sumitomo 2 way TS 090 II Receptacle Housing for Cam & Crank Sensors (Toyota # 90980-10959)	Part # CONN-101018

Pricing
1 +	$7.99
5 +	$7.75
25 +	$7.49
50 +	$7.25
100 +	$5.99
Information
Bmotorsports Part #	CONN-101018
Availability	In Stock
Shipping Weight	0.005 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

Sumitomo 2 way TS 090 II Receptacle Housing for Cam & Crank Sensors (Toyota # 90980-10959)
This connector receptacle is commonly found on Toyota and Lexus vehicles where the electrical connector is located remotely from the Crank or Cam position sensor instead of on or molded to the sensor itself.
Toyota # 90980-10959

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-100069	Sumitomo TS Sealed Series Male Terminal, Brass/Tin ( 20 - 16 gauge )
Seals	CONN-00145	Sumitomo HM / MT / TS Sealed Series wire seal, black ( 20 - 16 gauge )
Connector Only	CONN-101018	Sumitomo 2 way TS 090 II Receptacle Housing for Cam & Crank Sensors (Toyota # 90980-10959)
Connector Kit	CONN-76073	Sumitomo 2 way TS 090 II Receptacle Connector Kit for Cam & Crank Sensors (Toyota # 90980-10959)
Connector Pigtail	CONN-86073	Sumitomo 2 way TS 090 II Receptacle Connector Pigtail for Cam & Crank Sensors (Toyota # 90980-10959)
Mating Parts
Terminals	CONN-11856	Sumitomo TS / SL Female Terminal 0.5 - 1.25 mm2 ( 20 - 16 AWG )
Gold plated female terminals	CONN-100325	Sumitomo Part 6520-0349 For FRS GT86 or BRZ Tail Light, Toyota Oxygen Sensors
Seals	CONN-00145	Sumitomo HM / MT / TS Sealed Series wire seal, black ( 20 - 16 gauge )
Connector Only	CONN-100510	Sumitomo 2 way TS Plug Housing for Cam & Crank Sensors (Toyota # 90980-10947)
Connector Kit	CONN-75800	Sumitomo 2 way TS Plug Housing Kit for Cam & Crank Sensors (Toyota # 90980-10947)
Connector Pigtail	CONN-85800	Sumitomo 2 way TS Plug Housing Pigtail for Cam & Crank Sensors (Toyota # 90980-10947)

Specifications

Parameter Value
Number of Ways 2
Gender Receptacle/Female
Terminal Size 2.3mm
Terminal Type Flat
Min. Wire Gauge 20
Max. Wire Gauge 16

Applications:

2JZ & 2JZGTE Crank & Cam Sensor receptacle
1MZFE Crank & Cam Sensor receptacle
3MZFE Crank & Cam Sensor receptacle

Used In

Part #	Description
CONN-76073	Sumitomo 2 way TS 090 II Receptacle Connector Kit for Cam & Crank Sensors (Toyota # 90980-10959)
CONN-86073	Sumitomo 2 way TS 090 II Receptacle Connector Pigtail for Cam & Crank Sensors (Toyota # 90980-10959)
