Miata/Toyota 28 way ECU Connector Kit	Part # CONN-76219

Pricing
1 +	$14.99
10 +	$13.99
100 +	$12.99
500 +	Call for Pricing
Information
Bmotorsports Part #	CONN-76219
Availability	In Stock
Shipping Weight	0.1 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

Miata/Toyota 28 way ECU Connector Kit. Connector Kit. Terminals included.

This 28 Way ECU Plug connects to the ECU of many Toyota applications & NB Miata with MS Extra options.. Sometimes these break or a user needs to make a new harness or a new ECU connection. Equivalent of Toyota Connector 90980-11637, 90980–11637

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-100753	ECU Female Terminals, 0.3mm2 - 0.85mm2 ( 22 - 18 AWG)
17 Way Connector	CONN-100749	Miata/K Series Honda/Toyota 17 way ECU Plug
22 Way Connector	CONN-100756
24 Way Connector	CONN-100750	Miata/K Series Honda 24 way ECU Plug
28 Way Connector	CONN-100761	Miata/Toyota 28 way ECU Plug
31 Way Connector	CONN-100751	Miata/K Series Honda 31 way ECU Plug
17 Way Connector Kit	CONN-75910	Miata/K Series Honda 17 way ECU Plug Kit
22 Way Connector Kit	CONN-75989
24 Way Connector Kit	CONN-75911	Miata/K Series Honda 24 way ECU Plug Kit
28 Way Connector Kit	CONN-76219	Miata/Toyota 28 way ECU Connector Kit
31 Way Connector Kit	CONN-75912	Miata/K Series Honda 31 way ECU Plug Kit
17 Way Connector Pigtail	CONN-85910
22 Way Connector Pigtail	CONN-85989
24 Way Connector Pigtail	CONN-85911
31 Way Connector Pigtail	CONN-85912
Mating Parts
NB Miata 72 way ECU Header	CONN-100752	NB Miata/K Series Honda 72 Way ECU Header Receptacle
K Series 125 way ECU Header	CONN-100755	K Series Honda 125 way ECU Header Receptacle
K Series 108 way ECU Header	CONN-100757
K Series 86 way ECU Header	CONN-100759	K Series Honda 86 way ECU Header Receptacle

Applications

NB Miata with MS options
Equivalent of Toyota Connector 90980-11637, 90980–11637
Some other applications not specifically listed

Specifications

Parameter Value
Number of Ways 28
Gender Receptacle/Female
Terminal Size 0.3mm
Terminal Size (Secondary) 0.85mm
Terminal Type Flat
Min. Wire Gauge 22
Max. Wire Gauge 18

This product contains the following items:
	» 30 x ECU Female Terminals, 0.3mm2 - 0.85mm2 ( 22 - 18 AWG) Part # CONN-100753
	» 1 x Miata/Toyota 28 way ECU Plug Part # CONN-100761
