Flex Fuel / E85 Harness Breakout Adapter for GM E38/E67/E92 ECM	Part # CONN-86341

Pricing
1 +	$74.99
20 +	$68.50
50 +	Call for Pricing
Information
Bmotorsports Part #	CONN-86341
Availability	Special Order
Shipping Weight	0.1 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

Flex Fuel / E85 Harness Breakout Adapter for GM E38/E67/E92 ECM. An adapter used to break power out of the ignition connection on many GM applications, now run straight to E85/FF/ECA sensor connector and 6 foot sensor wire lead to run to the ECM.
if you need a different ECM terminal on the end of the lead, let us know in the order notes and we can accommodate. if you want it uncrimped so you can trim the wire lead and terminate please also be specific.

Applications:

GM Coil 12573190
GM Coil 10457730
GM Coil 190005218
GM Coil 12558693
GM Coil 12558948
GM Coil 12570616
LQ9 Coil
Some LS2, LS3, LS7 and LS9 Coils
MANY more GM, MSD, Accel and other coils

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Connector Only	CONN-52366	GM Delphi / Packard - 4 way GT 150 3.5mm Centerline male connector Assembly for some GM truck ignition coils (index keyway) (connector and TPA)
Seal	CONN-56559	GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
Terminal	CONN-56468	GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Connector Kit	CONN-75636	GM Delphi / Packard - 4 way GT 150 3.5mm Centerline male connector Kit for some GM truck ignition coils (index keyway)
Connector Pigtail	CONN-85636	GM Delphi / Packard - 4 way GT 150 3.5mm Centerline male connector Pigtail for some GM truck ignition coils (index keyway)
Associated Parts
Connector Only	CONN-100727	4 Way Connector Receptacle for Coils & Sensor Applications
Terminal	CONN-100730	Pull to seat Male Terminal for 150.2 & GT 150 3.5mm receptacles in 3,4,5,6 way
Connector Kit	CONN-75861	4 Way Connector Receptacle Kit for Coils & Sensor Applications
Connector Pigtail	CONN-85861	4 Way Connector Receptacle Pigtail for Coils & Sensor Applications
Associated Parts
Connector Only	CONN-100858	GM Delphi / Packard - 3-Way GT 150 Plug Assembly for Fuel Sensor Applications
Terminal	CONN-56456	GM Delphi / Packard - GT 150 Female Terminal ( 20 - 16 gauge )
Connector Kit	CONN-75811	GM Delphi / Packard - 3-Way GT 150 Plug kit for Fuel Sensor Applications
Connector Pigtail	CONN-85811	GM Delphi / Packard - 3-Way GT 150 Plug pigtail for Fuel Sensor Applications
Associated Parts
Ethanol Sensor	SNSR-25032	Continental Ethanol Content Sensor / Flex Fuel Sensor Kit
Extension
Extension	CONN-85889	GM Delphi / Packard - 4 way GT 150 3.5mm Centerline Connector Extension for LS/LT & Truck applications

Applications

GM Coil 12573190
GM Coil 10457730
GM Coil 190005218
GM Coil 12558693
GM Coil 12558948
GM Coil 12570616
LQ9 Coil
Some LS2, LS3, LS7 and LS9 Coils
MANY more GM, MSD, Accel and other coils

Specifications

Parameter Value
Gender Receptacle/Female
Terminal Size 3.5mm
Terminal Type Flat
Min. Wire Gauge 18
Max. Wire Gauge 16
