6 Way Pigtail Mate to GM/Nissan TPS/DBW	Part # CONN-86409

Pricing
1 +	$13.99
Information
Bmotorsports Part #	CONN-86409
Availability	In Stock
Shipping Weight	0.035 Lbs.
Shipping Location	VA (Shipping Info)
	Quantity:

Description

6 Way Receptacle Pigtail Mate to GM/Nissan TPS/DBW. Fully populated pigtail with 12" wire leads.

Mates to the Accelerator Pedal Sensor Connector Plug. Compatible with Chevrolet, Fiat, Hyundai, VW, Kia, Mitsubishi, Nissan, Saab

Associated & Mating Parts

Relationship	Part #	Description
Associated Parts
Terminals	CONN-00196	Male Terminals for Bosch LSU 4.9 Receptacle Connector
Seals	CONN-00193	Seals for Bosch wide flat connector for LSU 4.0 and LSU 4.9 sensor
Connector Housing	CONN-101566	6 Way Mate to GM/Nissan TPS/DBW
Connector Kit	CONN-76409	6 Way Kit Mate to GM/Nissan TPS/DBW
Pigtail	CONN-86409	6 Way Pigtail Mate to GM/Nissan TPS/DBW
Mating Parts
Terminals	CONN-00194	Terminals for Bosch 6-way wide flat connector for LSU 4.0 sensor
Seals	CONN-00193	Seals for Bosch wide flat connector for LSU 4.0 and LSU 4.9 sensor
Connector Housing	CONN-101565	6 Way Connector Plug for GM/Nissan Throttle Body
Connector Kit	CONN-76404	6 Way Connector Plug Kit for GM/Nissan Throttle Body
Pigtail	CONN-86404	6 Way Connector Plug Pigtail for GM/Nissan Throttle Body
Extension	CONN-86345

Specifications

Parameter Value
Number of Ways 6
Gender Receptacle/Female
Terminal Size 1.5mm
Terminal Type Flat
Min. Wire Gauge 20
Max. Wire Gauge 18

This product contains the following items:
	» 6 x 20AWG Automotive TXL Wire Black Part # WIRE-00458S
	» 6 x Seals for Bosch wide flat connector for LSU 4.0 and LSU 4.9 sensor Part # CONN-00193
	» 6 x Male Terminals for Bosch LSU 4.9 Receptacle Connector Part # CONN-00196
	» 1 x 6 Way Mate to GM/Nissan TPS/DBW Part # CONN-101566
