GM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT) or Manifold Air Temperature Sensor # 12146830 , Gray with Keyway Connector Part # SNSR-02058
GM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT) or Manifold Air Temperature Sensor # 12146830 , Gray with Keyway Connector GM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT) or Manifold Air Temperature Sensor # 12146830 , Gray with Keyway Connector GM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT) or Manifold Air Temperature Sensor # 12146830 , Gray with Keyway Connector
Pricing
1 + $14.99
5 + $14.49
10 + $13.99
25 + $13.49
50 + $12.99
100 + $12.49
300 + $11.99
Information
Bmotorsports Part # SNSR-02058
Availability In Stock
Shipping Weight 0.028 Lbs.
Shipping Location VA   (Shipping Info)
Options
Mounting Option
Ship Estimator Quantity:

Description

FEATURES:

  • Genuine Delphi Sensor
  • Robust Design
  • Cost Effective
  • 100% Calibration Certified
  • Thermistor Technology
  • Typical Voltage Supply: 5V DC
  • Operating Temperature: -40 C to 135 C
  • Sensor Body Material: PEI 30% GF
  • Hex Size: 18.90 mm (3/4")
  • Thread Size: 3/8" - 18 NPTF
  • Thread Sealant: GM09985490
  • Sealing Pressure: 145 kPa
  • Thermal Time Constant: ** 60 sec
  • Dissipation Constant: * 18 mW/degC
  • Overall Wieght: 13.20 g
  • Color: Gray


Associated & Mating Parts

Relationship Part # Description
Associated Parts
Fast Response 3/8 NPT IAT SNSR-02057Fast-Response GM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT ) or Manifold Air Temperature Sensor # 25036751 - 25037225 - 25037034 *RECOMMENDED*
Fast Response M14x1.5 IAT SNSR-02063Fast-Response (Metric M14 x 1.5) GM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT ) or Manifold Air Temperature Sensor
Fast Response Grommet IAT SNSR-02060GM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT) or Manifold Air Temperature Sensor, Black with Keyway Connector
Standard Response Plastic IAT SNSR-02058GM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT) or Manifold Air Temperature Sensor # 12146830 , Gray with Keyway Connector
Standard Response Plastic IAT (Mushroom Keyway) SNSR-02055GM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT) or Manifold Air Temperature Sensor # 12110446 , Black with Mushroom Connector
Preferred Mating Connector (Shrouded with rear release):
Connector Only CONN-51560GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female assembly for IAT
Terminals CONN-56468GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Seals CONN-56559GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
Connector Kit CONN-75643GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Kit for IAT
Connector Pigtail CONN-85643GM Delphi / Packard - 2-way Shrouded GT 150 3.5mm centerline sealed female Pigtail for IAT
Non-preferred Mating Connector (Unshrouded with front release):
Connector Only CONN-51561GM Delphi / Packard - 2-way un-shrouded GT 150 3.5mm centerline sealed female assembly for IAT
Terminals CONN-56468GM Delphi / Packard - GT 150 3.5mm Centerline Female Terminal, 18 gauge [ .75 - .8mm2] Tin Plated
Seals CONN-56559GM Delphi / Packard - GT 150 Cable Seal, Yellow ( 20 - 16 gauge ) for 3.5mm centerline only
Connector Kit CONN-75644GM Delphi / Packard - 2-way Un-shrouded GT 150 3.5mm centerline sealed female Kit for IAT
Connector Pigtail CONN-85644GM Delphi / Packard - 2-way un-shrouded GT 150 3.5mm centerline sealed female Pigtail for IAT
Extensions
IAT / MAT / ACT Wiring Extension CONN-85584GM Delphi / Packard - IAT / MAT / ACT Extender Harness

Specifications








Applications

The following is a list of applications:

  • Genuine Delphi Sensor
  • Intake Air Temperature Sensor for ZW220 ZW250 ZX110-3 Excavator Parts
  • Hitachi Excavator ZAXIS110-3 ZAXIS200-3 ZAXIS330-3
  • For John Deere Excavator 135D 135G 190DW 190GW 220DW 225DLC 230GW 245GLC
  • John Deere Excavator 6UZ1XZSA-01 6WG1XZSA-02
  • John Deere Excavator 450DLC 470GLC 650DLC 670GLC 850DLC 870GLC
  • Lightweight air temp sensor in comparison to brass body Delphi sensors


Used In

Part # Description
SNSR-02058PKGM Delphi / Packard Intake Air Temperature Sensor ( IAT / MAT / ACT) or Manifold Air Temperature Sensor # 12146830 , Gray with Keyway Connector Pigtail Kit
